DJI Dock 2 (Overseas Edition)

Spesifikasi

General
Product Name: DJI Dock 2
Total Weight: 34 kg (without aircraft)
The actual product weight may vary due to differences in batch materials and external factors.

Dimensions:
– Dock Cover Opened: 1228×583×412 mm (L×W×H)
– Dock Cover Closed: 570×583×465 mm (L×W×H)
The above data does not include the height of the wind speed gauge (145 mm) but includes the height of the mounting base brackets (55 mm).

Input Voltage: 100-240 V (AC), 50/60 Hz
Input Power: Max 1000 W
Operating Temperature: -25° to 45° C (-13° to 113° F)
When the ambient temperature is below -20° C (-4° F), the dock is in standby status, and the aircraft cannot perform flight tasks.

Ingress Protection Rating: IP55
Number of Drones Accommodated: 1
Max Allowable Landing Wind Speed: 8 m/s
Max Operating Altitude: 4000 m
Receiving Frequency of RTK Base Station Satellite:
Simultaneously receive:
– GPS: L1 C/A, L2
– BeiDou2: B1l, B2l, B3l
– BeiDou3: B1l, B3l
– GLONASS: L1, L2
– Galileo: E1, E5B

Positioning Accuracy of RTK Base Station:
– Horizontal: 1 cm + 1 ppm (RMS)
– Vertical: 2 cm + 1 ppm (RMS)

===================
Charging Performance
Output Voltage: 28 V DC
Charging Time: 32 minutes

The data was measured when charging the aircraft (when powered off) from 20% to 90% in a 25° C (77° F) environment.

===================
Video Transmission
Video Transmission System: O3 Enterprise
Operating Frequency:
– 2.4000-2.4835 GHz
– 5.725-5.850 GHz

Antenna: Built-in 4 antennas, 2T4R, supports intelligent switching
Transmitter Power (EIRP):
– 2.4 GHz: – 5.8 GHz:

===================
Air Conditioning System
Operating Voltage: 28 V DC
Air Conditioning Type: TEC Air Conditioning

===================
Backup Battery
Battery Capacity: 12 Ah
Output Voltage: 12 V
Battery Type: Lead-acid battery
Battery Life: > 5 hours

Measured with a fully charged backup battery in a 25° C (77° F) environment. ‌After a power outage, the dock does not support functions like aircraft charging, air conditioning, dock cover heating, and wind speed gauge heating. Always check malfunctions promptly.

===================
Network Access
Ethernet Access: 10/100/1000Mbps adaptive Ethernet port

===================
Sensor
Wind Speed Sensor: Supported
Rainfall Sensor: Supported
Ambient Temperature Sensor: Supported
Water Immersion Sensor: Supported
In-Cabin Temperature Sensor: Supported
In-Cabin Humidity Sensor: Supported

===================
Security Camera (External)
Resolution: 1920×1080
Field of View (FOV): 151°
Auxiliary Light: Auxiliary White Light

===================
Security Camera (Internal)
Resolution: 1920×1080
Field of View (FOV): 151°
Auxiliary Light: Auxiliary White Light

===================
Lightning Protection
AC Power Port: 20 kA (rated value), meets EN 61643-11 Type 2 and IEC 61643-1 Class Ⅱ protection level requirements
Ethernet Port: 10 kA (Itotal )，meets EN/IEC 61643-21 Category C protection level requirements

===================
Supported Software
Applications: DJI Pilot 2 (connects to DJI Dock 2 via DJI RC Pro Enterprise for deployment and commissioning)
Cloud Platform:
– DJI FlightHub 2 (supported by default)
– Third-party cloud platforms (accessed through DJI Cloud API)

===================
Expansion Capability
Open Protocol: DJI Cloud API
Edge Computing: Supports data communication with external switches

===================
Others
Guaranteed software updates until: 2025/12/31
